Masonry Magazine January 1984 Page. 44
GIANT-P-307-B
"OPEN THROAT" its EFFICIENCY is in its SIMPLICITY CONCRETE-GROUT MACHINE
MASONRY BLOCK SLABS FOUNDATIONS FORM FILLS COLUMNS MUD JACKING, ETC. Fewer moving parts means less repairs. Driving pistons are to sides of machine for easy maintenance. Any pump speed from 0 to maximum.
DEALER RESPONSE INVITED FOR LITERATURE WRITE:
GIANT INDUSTRIES CORPORATION
8481 Whittier Boulevard
Pico Rivera, California 90660
(213) 699-6388 or 723-5218
SINCE 1957
New Foam Aids in Insulating Masonry Walls
The new foam-in-place insulation system developed by The Upjohn Co.'s CPR Division, Torrance, Calif., is showing promise as a cost-effective energy conservator in both new and existing masonry walls. Two recent applications in Texas and Arizona underscore the advantages of the low density formalde-hyde-free product.
At Adams Plaza No. 2, a two-story retail/office structure in Houston, the foam was used to fill the cores of a new interlocking type of energy-efficient concrete block designed to be laid without mortar. The calculated R-value (resistance to heat flow) of the insulated 8 in. walls is approximately 13 vs. 3 for uninsulated walls of the same block.
"The foam's resistance to heat flow, combined with the thermal-mass effect afforded by masonry construction, is expected to result in substantial savings in air conditioning and heating costs," said Ray Lebbetter, president of Lock-Block Inc. of Houston, developer and manufacturer of the interlocking block.
The Poly-C foam is supplied to the contractor in the form of two liquid components, which are combined using special metering and mixing equipment, and poured into the cavities to be installed. The rising foam flows and completely fills the cavity.
The interlocking block are made of lightweight, fiber-reinforced concrete, and are 8 in. thick, 12 in. high and 36 in. long. A shiplap joint on each edge assures locking action without mortar.
Suitability for Retrofitting
The recent insulation of a house in Arizona showed the suitability of Poly-C for retrofitting buildings of masonry cavity-wall construction. In this case the material 44 MASONRY-JANUARY, 1984
ORIGINATORS OF
Pre-Fabricated Glass Block Panels
*
CUSTOM MADE TO YOUR REQUIREMENTS
NATIONAL DISTRIBUTOR
PITTSBURGH CORNING
SCHALKE GLASS BLOCK-GERRIX HOLLOW
GLASS BLOCK
*
MANY STYLES AND SHAPES
SASH REPLACEMENT
*
SPECIALISTS IN THE INSTALLATION OF
GLASS BLOCK
FRED BEYER
Since 1910
7810 S. Claremont Chicago, III. 60620
(312) PR 8-4300
Poly-C polycarbanilide foam insulation is supplied in the form of two liquid components which are processed at the construction site and poured into the cavities of concrete block. Reaction is not affected by damp conditions.
