Planks and WALKBOARDS
Similar safety rules apply for manufactured walkboards as well. Walkboards are typically made from aluminum with either a plywood top or aluminum top and measure 19 inches wide. Load-bearing capacities are normally stamped right on the walkboard and are usually either 50 pounds per square foot (psf) or 75 psf, depending on the length and width of the walkboard. Capacities for both plank and walkboards assume uniform loading to reach their rated capacities, not point loads. Point loads have the
QUALITY MASONRY TOOLS
KING BRICK HOO
WTOOLS
The
www.carwoldtools.com
4619 Din Creek Road House Springs, M. 63051
Phone: (630) 671-4187 Fac(36) 375-3625
Toll Free: 1-800-245-3544
CIRCLE 154 ON READER SERVICE CARD
Engineered Wood
Specialists!
For
Industrial
Applications...
Scaffold
Plank
MasterPlank
• TecLam
• Microllam
Concrete
Forming
Building
& More!
ACCAUSEY LUMBER CO.
Roseville, Michigan 800.365.9663
Fax 586,294,1505 www.mccauseylumber.com
CIRCLE 160 ON READER SERVICE CARD
If a contractor suspects that a plank
has been overstressed and has any doubts about its condition, it should be rejected.
entire load centered in one spot instead of a uniform distribution of the weight along the entire length and width of the plank or walkboard. Other walkboards can be constructed of steel, or steel and expanded metal. Use of these materials will allow contractors to attain higher load capacities than are normally attainable with either wood or manufactured plank.
Selecting Scaffold Plank
WHEN BUYING or renting scaffold frames and planking, contractors need to consider their needs carefully and be prepared to answer three important questions:
* What materials will be used on the job?
* How will those materials be stocked and stored?
* How many workers will be working from a scaffold plank at one time?
Masonry work generally is considered light-duty (25 psf) or medium-duty (50 psf) loading, but this doesn't always hold true. A scaffold plank that must hold palletized
