Masonry Magazine April 2005 Page. 28
SCAFFOLD PLANK
in Houston, says the next common mistake is in how the planks are stored while not in use.
"Where you lose your boards is when they're stacked-this is with any kind of wood. This is a thing that needs to be yelled at contractors," says Cook. "When you get done with your boards and you stack them out in the field-even if you stack them up indoors- if you stack them up wet, two or three months later you've lost a lot of them. Any kind of wood that you make scaffold planks out of, rot is going to take place."
THE ORIGINAL FOR OVER 40-YEARS
PLANK-TIE
YOUR NAME IMPRINTED HERE
000000000
Manufactured
by ISI
Scaffold
Plank
Protection
180 Mill Street, Waynesboro, VA 22980
(540) 949-6839
www.plank-tie.com
The Original since 1947! Made in the USA
CIRCLE 173 ON READER SERVICE CARD
PROTO-II Wall Systems
The Next Generation in Post-Tension Masonry
Proto-II™ Wall Systems licenses masonry installers throughout the country to build their patented post tensioned masonry fences and retaining walls.
Proto-II™ Masonry Fences and Retaining Walls provide:
* Huge savings over conventional masonry
* Faster Installation
* Higher strengths and load capacities
Do you have the Proto-IIT™ advantage?
PROTO-II™ Wall Systems
P.O. Box 69395
Oro Valley, AZ 85737
(602) 319-4596
rcampbell@protoii.com
www.protoii.com
CIRCLE 305 ON READER SERVICE CARD
New Plank Tester Assists in Inspection
Ten years ago, Carl Cook, President of Indian Mill in Houston, needed a way to test planks before sending them to customers. After several prototypes using pneumatics, air cylinders and other types of equipment, Cook invited several construction industry, research and OSHA folks to have a two-day "skull session" on how to build an after-market plank tester that could complete OSHA and ANSI grade evaluations. This brainstorming session, along with two more years of prototypes and trials, brought together the stationary SPT-5 and mobile SPT-5M Solid State Scaffold Plank Testers.
Both models utilize only one moving part-the ball-screw motor that operates the pressure foot assembly - to minimize maintenance and hardware failures. They also have electronic testing with digital accuracy and exact measuring, the ability to do light, medium and heavy-duty testing, four programmable test settings, a rugged design and the capacity to test planks of any length.
"The ball-screw motor brings the foot down, and the foot finds the board," says Cook. "It's flexible, so if the board is bent up or down or warped, the foot will 'find' it, then activate a switch and put a pound of pressure to make sure that's where the board is located. This activates the switch to start the testing at that zero point and means you're doing a true test on the board."
Are there typically a lot of plank failures on masonry job sites to warrant the need for a plank tester?
"A lot? Any is a real problem," Cook replies. "When somebody gets hurt on the job, the insurance people show up, OSHA gets involved. There are always fines, inspections and other things that really bog things down. Besides that, it really hurts to get hurt.
"You could have 20,000 planks up there, but it only takes one to break to create a huge, huge problem," he adds.
Cook says that, while small and medium-sized businesses may not be able to warrant purchasing Indian Mills' plank tester, larger businesses might be able to justify owning one. He also says that a masonry association in Montreal recently purchased one of the testers and has made it available for use by its members.
"You still have to look at the board to see if you've got saw curves, holes and rot starting," he says. "It's not the 'end all, be all but it's a tool to do finished testing."
