BLOCK INNOVATION
with the adjacent units. Each individual insert interlocks with the next to eliminate any air gaps as well as thermal bridging.
The SSB is pre-insulated at the manufacturing plant for immediate use once delivered to the jobsite. Walls are constructed with conventional mortar, the only difference is that cach course is inverted from the previous course.
Basic block design
Laying Solar/Stud Block
THE SOLAR/STUD BLOCK consists of a unique, cross-section design. The outer section is composed of ribs that function as both an anchoring system for the insert and a fastening point for veneers that are mechanically fastened. The center section consists of self-aligning cores that may be partially or fully reinforced. The interior component of the unit consists of a concrete "stud." The stud measures two inches wide and 75/8-inch high. This stud contains an impression that, when coupled with the course above, forms a chase for mechanical installations such as electrical wiring. These concrete studs function as a fastening point for the interior finish, such as sheet rock. The studs will accept nail, glue or screw as a fastening method. No additional insulation is placed between the studs.
How it works
THE PRIMARY PURPOSE for the SSB is to save energy. The principle behind it is referred to as "Thermal Diffusivity." The concrete within the block absorbs heat. This is accomplished either through passive solar gain or conventional heating systems. The SSB then releases heat back into the interior of the building during the evening and overnight hours, providing longer hours of comfort in the cold months.
55B Interior Wall
